6. Reconfiguration Interface and Dynamic
Reconfiguration
This chapter explains the purpose and the use of the Arria 10 reconfiguration interface
that is part of the Transceiver Native PHY IP core and the Transceiver PLL IP cores.
Dynamic reconfiguration is the process of dynamically modifying transceiver channels
and PLLs to meet changing requirements during device operation. Arria 10 transceiver
channels and PLLs are fully customizable, allowing a system to adapt to its operating
environment. You can customize channels and PLLs by dynamically triggering
reconfiguration during device operation or following power-up. Dynamic
reconfiguration is available for Arria 10 Transceiver Native PHY, fPLL, ATX PLL, and
CMU PLL IP cores.
Use the reconfiguration interface to dynamically change the transceiver channel or PLL
settings for the following applications:
• Fine tuning signal integrity by adjusting TX and RX analog settings
• Enabling or disabling transceiver channel blocks, such as the PRBS generator and
the checker
• Changing data rates to perform auto negotiation in CPRI, SATA, or SAS
applications
• Changing data rates in Ethernet (1G/10G) applications by switching between
standard and enhanced PCS datapaths
• Changing TX PLL settings for multi-data rate support protocols such as CPRI
• Changing RX CDR settings from one data rate to another
• Switching between multiple TX PLLs for multi-data rate support
The Native PHY and Transmit PLL IP cores provide the following features that allow
dynamic reconfiguration:
• Reconfiguration interface
• Configuration files
• Feature to add PMA analog settings (optional) to the Configuration files (Native
PHY only)
• Multiple reconfiguration profiles (Native PHY and ATX PLL)
• Embedded reconfiguration streamer (Native PHY and ATX PLL)
• Altera Debug Master Endpoint (ADME)
• Optional reconfiguration logic
