Assign To
TX serial data pin.
Syntax
set_instance_assignment -name XCVR_VCCR_VCCT_VOLTAGE <value> -to
<tx_serial_data pin name>
Related Information
Arria 10 Device Datasheet
8.6.5. XCVR_A10_TX_SLEW_RATE_CTRL
Pin planner or Assignment Editor Name
Transmitter Slew Rate Control
Description
Specifies the slew rate of the output signal. The valid values span from the slowest
rate to the fastest rate.
Note: Slew_R6 and Slew_R7 are not used.
Table 319. Available Options
Value Description
SLEW_R0 to SLEW_R5 R0 is the slowest rate. R5 is the fastest rate.
If QSF is not specified, the following table lists the default values.
Table 320. Default Values
PCIe
Value Default Slew Rate
PCIe Gen1 SLEW_R4
PCIe Gen2 SLEW_R5
PCIe Gen3 SLEW_R5
Non-PCIe
Value
(VCCT/VCCR)
Default Slew Rate
Data rate < 1G
Data rate ≥ 1G to <
3G
Data rate ≥ 3G to <
6G
Data rate ≥ 6G
0.95 V SLEW_R0 SLEW_R2 SLEW_R3 SLEW_R5
1.03 V SLEW_R1 SLEW_R3 SLEW_R4 SLEW_R5
1.12 V SLEW_R2 SLEW_R4 SLEW_R5 SLEW_R5
Assign To
TX serial data pin.
8. Analog Parameter Settings
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
599
