Intel Arria 10 User Manual

Table 324. Available Options
Value Description
FIR_POST_2T_POS Positive post-tap 2
FIR_POST_2T_NEG Negative post-tap 2
Assign To
TX serial data pin.
Syntax
set_instance_assignment -name
XCVR_A10_TX_PRE_EMP_SIGN_2ND_POST_TAP <value> -to <tx_serial_data
pin name>
8.7.5. XCVR_A10_TX_PRE_EMP_SWITCHING_CTRL_PRE_TAP_1T
Pin planner or Assignment Editor Name
Transmitter Pre-Emphasis First Pre-Tap Magnitude
Description
Controls the magnitude of the first pre-tap for pre-emphasis. The default value is 0.
Table 325. Available Options
Value Description
0 – 16 Magnitude 0 – 16
Note: Refer to Arria 10 Pre-Emphasis and Output Swing Settings spreadsheet for selecting
legal pre-emphasis and differential output voltage settings.
Assign To
TX serial data pin.
Syntax
set_instance_assignment -name
XCVR_A10_TX_PRE_EMP_SWITCHING_CTRL_PRE_TAP_1T <value> -to
<tx_serial_data pin name>
Related Information
Arria 10 Pre-Emphasis and Output Swing Settings
8.7.6. XCVR_A10_TX_PRE_EMP_SWITCHING_CTRL_PRE_TAP_2T
Pin planner or Assignment Editor Name
Transmitter Pre-Emphasis Second Pre-Tap Magnitude
8. Analog Parameter Settings
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
602

Intel Arria 10 Specifications

General

Transceiver Data Rate	Up to 17.4 Gbps
Transceiver Protocols Supported	CPRI, JESD204B
Transceiver Power Consumption	Varies depending on configuration and data rate. Refer to Intel Arria 10 device power estimation tools.
Transceiver Features	Clock data recovery
Power Consumption per Channel	Varies depending on data rate and equalization settings. Refer to Intel Arria 10 device power estimation tools.
Transceiver Type	FPGA integrated transceiver
Operating Temperature Range	-40°C to 100°C (Industrial)
Number of Transceiver Channels	up to 96 full-duplex
