Analog Parameter Setting Pin Planner or Assignment Editor
Name
Assignment
Destination
Usage Guideline
XCVR_A10_RX_ADP_DFE_FXTAP6_
SGN
Receiver Decision Feedback
Equalizer Fixed Tap Six Sign
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP7 Receiver Decision Feedback
Equalizer Fixed Tap Seven
Coefficient
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP7_
SGN
Receiver Decision Feedback
Equalizer Fixed Tap Seven Sign
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP8 Receiver Decision Feedback
Equalizer Fixed Tap Eight Coefficient
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP8_
SGN
Receiver Decision Feedback
Equalizer Fixed Tap Eight Sign
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP9 Receiver Decision Feedback
Equalizer Fixed Tap Nine Coefficient
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP9_
SGN
Receiver Decision Feedback
Equalizer Fixed Tap Nine Sign
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP10 Receiver Decision Feedback
Equalizer Fixed Tap Ten Coefficient
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP10_
SGN
Receiver Decision Feedback
Equalizer Fixed Tap Ten Sign
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP11 Receiver Decision Feedback
Equalizer Fixed Tap Eleven
Coefficient
RX serial data DFE
XCVR_A10_RX_ADP_DFE_FXTAP11_
SGN
Receiver Decision Feedback
Equalizer Fixed Tap Eleven Sign
RX serial data DFE
Table 305. Transmitter Analog Parameter Settings
Analog Parameter Setting Pin Planner or Assignment Editor
Name
Assignment
Destination
Usage Guideline
XCVR_A10_TX_LINK Transmitter Link Type TX serial data Chip-to-chip or backplane
XCVR_A10_TX_TERM_SEL Transmitter On-Chip Termination TX serial data On chip termination
XCVR_A10_TX_COMPENSATION_EN Transmitter High-Speed
Compensation
TX serial data PDN ISI compensation
XCVR_VCCR_VCCT_VOLTAGE VCCR_GXB/VCCT_GXB Voltage TX serial data VCCR/VCCT voltage
XCVR_A10_TX_SLEW_RATE_CTRL Transmitter Slew Rate Control TX serial data Slew Rate
XCVR_A10_TX_PRE_EMP_SIGN_PR
E_TAP_1T
Transmitter Pre-Emphasis First Pre-
Tap Polarity
TX serial data Pre-emphasis
XCVR_A10_TX_PRE_EMP_SIGN_PR
E_TAP_2T
Transmitter Pre-Emphasis Second
Pre-Tap Polarity
TX serial data Pre-emphasis
XCVR_A10_TX_PRE_EMP_SIGN_1S
T_POST_TAP
Transmitter Pre-Emphasis First
Post-Tap Polarity
TX serial data Pre-emphasis
XCVR_A10_TX_PRE_EMP_SIGN_2N
D_POST_TAP
Transmitter Pre-Emphasis Second
Post-Tap Polarity
TX serial data Pre-emphasis
XCVR_A10_TX_PRE_EMP_SWITCHI
NG_CTRL_PRE_TAP_1T
Transmitter Pre-Emphasis First Pre-
Tap Magnitude
TX serial data Pre-emphasis
XCVR_A10_TX_PRE_EMP_SWITCHI
NG_CTRL_PRE_TAP_2T
Transmitter Pre-Emphasis Second
Pre-Tap Magnitude
TX serial data Pre-emphasis
continued...
8. Analog Parameter Settings
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
587
