Intel Arria 10 User Manual

Protocol Transceiver PHY IP
Core
PCS Support Transceiver
Configuration Rule
(9)
Protocol Preset
(10)
SONET/SDH STS-48/
STM-16 (2.5G) via
SFP/TFI-5.1
Native PHY IP core Standard Basic/Custom
(Standard PCS)
SONET/SDH OC-48
SONET/SDH STS-12/
STM-4 (0.622G) via
SFP/TFI-5.1
Native PHY IP core
(19)
Standard Basic/Custom
(Standard PCS)
SONET/SDH OC-12
Intel QPI 1.1/2.0 Native PHY IP core PCS Direct PCS Direct User created
SD-SDI/HD-SDI/3G-
SDI
Native PHY IP core Standard Basic/Custom
(Standard PCS)
3G/HD SDI NTSC
3G/HD SDI PAL
Vx1 Native PHY IP core Standard Basic/Custom
(Standard PCS)
User created
DisplayPort
(20)
Native PHY IP core Standard Basic/Custom
(Standard PCS)
User created
1.25G/ 2.5G
10G GPON/EPON
Native PHY IP core Enhanced Basic (Enhanced PCS) User created
2.5G/1.25G GPON/
EPON
Native PHY IP core Standard Basic/Custom
(Standard PCS)
User created
16G/10G Fibre
Channel
Native PHY IP core Enhanced Basic (Enhanced PCS) User created
8G/4G/2G/1G Fibre
Channel
Native PHY IP core Standard Basic/Custom
(Standard PCS)
User created
EDR Infiniband x1, x4 Native PHY IP core Enhanced (low latency
mode)
PCS Direct
Basic (Enhanced PCS)
PCS Direct
User created
FDR/FDR-10 Infiniband
x1, x4, x12
Native PHY IP core Enhanced Basic (Enhanced PCS) User created
SDR/DDR/QDR
Infiniband x1, x4, x12
Native PHY IP core Standard Basic/Custom
(Standard PCS)
User created
CPRI v6.1 12.16512/
CPRI v6.0 10.1376 Gbps
Native PHY IP core Enhanced 10GBASE-R 1588
10GBASE-R
User created
CPRI 4.2/OBSAI RP3
v4.2
Native PHY IP core Standard CPRI (Auto) / CPRI
(Manual)
CPRI 9.8Gbps Auto
Mode
continued...
(9)
For more information about Transceiver Configuration Rules, refer to Using the Intel Arria
10Transceiver Native PHY IP Core section.
(10)
For more information about Protocol Presets, refer to Using the Intel Arria 10Transceiver
Native PHY IP Core section.
(19)
The minimum operational data rate is 1.0 Gbps for both the transmitter and receiver. For
transmitter data rates less than 1.0 Gbps, oversampling must be applied at the transmitter.
For receiver data rates less than 1.0 Gbps, oversampling must be applied at the receiver.
(20)
To meet DisplayPort TX electrical full compliance to VESA DisplayPort Standard version 1.3 and
VESA DisplayPort PHY Compliance Specification version 1.2b , VCCT_GXB & VCCR_GXB needs
to be 1.03V or higher. Test Refer to AN745: Design Guidelines for DisplayPort and HDMI
Interfaces for further details.
2. Implementing Protocols in Arria 10 Transceivers
UG-01143 | 2018.06.15
Intel
®
Arria
®
10 Transceiver PHY User Guide
44
