Keithley DMM7510 Reference Manual

Section
3: Functions and features Model DMM7510 7½ Digit Graphical Sampling Multimeter
Reference Manual
3-22 DMM7510-901-01 Rev. B / May 2015
Using the front panel to set fill mode:
1. Press the MENU key.
2. Under Measure, select Reading Buffers. The MANAGE READING BUFFERS window is
displayed.
Figure 112: MANAGE READING BUFFERS window
3. Select a reading buffer from the list. For example, select testData. The settings for testData
are displayed.
4. Select the Fill Mode option.
5. Press the HOME key to return to the Home screen.
Using SCPI commands to set the buffer fill mode:
To set the testData reading buffer fill mode to continuous, send the following command:
TRACe:FILL:MODE CONT, "testData"
To set the defbuffer1 reading buffer fill mode to fill once, send the following command:
TRACe:FILL:MODE ONCE, "defbuffer1"
To get the fill mode that is set, send the following command:
TRACe:FILL:MODE? "defbuffer1"
Where a return of ONCE indicates the buffer is set to fill once and a return of CONT indicates the buffer
is set to fill continuously.

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
