Keithley DMM7510 Reference Manual

Model DMM7510
7½ Digit Graphical Sampling Multimeter Reference Manual Section 3:
Functions and features
DMM7510-901-01 Rev. B / May 2015 3-27
Using the front panel to save or append buffer content to files:
1. Insert a USB flash drive into the USB port.
2. Press the MENU key.
3. Under Measure, select Reading Buffers. The MANAGE READING BUFFERS window is
displayed.
4. Select the reading buffer that you want to save. For example, select testData.
Figure 116: MANAGE READING BUFFERS window
5. Select the Save To USB button. A keyboard is displayed.
6. Enter the name of the file in which to save the readings.
You only have to enter the name of the file you want to save. It is not necessary to enter the file
extension. All files are saved as .csv files.
7. Press OK on the keyboard.
8. Select Yes to confirm saving the file. When the MANAGE READING BUFFERS window is
displayed again, the file is saved.
9. Press the HOME key to return to the Home screen.
Using SCPI commands to save or append buffer content to files:
Before using any of these commands, insert a USB flash drive into the USB port.
To save readings and formatted timestamps from the default buffer to a file named myData.csv on
a USB flash drive, send the following command:
TRACe:SAVE "/usb1/myData.csv", "defbuffer1"
To save readings and formatted timestamps from a reading buffer named testData to a file named
myData.csv on a USB flash drive, send the following command:
TRACe:SAVE "/usb1/myData.csv", "testData"

Keithley DMM7510 Specifications

General

Resolution	7.5 digits
DC Voltage Range	100 mV to 1000 V
AC Voltage Range	100 mV to 750 V
DC Current Range	10 µA to 10 A
Resistance Range	10 Ω to 1 GΩ
Sampling Rate	1 MS/s
Memory	27.5 million readings
Display	5 inch capacitive touchscreen
AC Voltage Accuracy	±0.06% of reading
AC Current Range	10 A
Connectivity	USB, LAN, GPIB
