Commands Quick Reference 4
Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide 55
:OVLenable <mask>
(see page 154)
:OVLenable? (see
page 154)
<mask> ::= 16-bit integer in NR1
format as shown:
Bit Weight Input
--- ------ ----------
10 1024 Ext Trigger Fault
9 512 Channel 4 Fault
8 256 Channel 3 Fault
7 128 Channel 2 Fault
6 64 Channel 1 Fault
4 16 Ext Trigger OVL
3 8 Channel 4 OVL
2 4 Channel 3 OVL
1 2 Channel 2 OVL
0 1 Channel 1 OVL
n/a :OVLRegister? (see
page 156)
<value> ::= integer in NR1
format. See OVLenable for <value>
:PRINt [<options>]
(see page 158)
n/a
<options> ::= [<print
option>][,..,<print option>]
<print option> ::= {COLor |
GRAYscale | PRINter0 | PRINter1 |
BMP8bit | BMP | PNG | NOFactors |
FACTors}
<print option> can be repeated up
to 5 times.
:RUN (see page 159) n/a n/a
n/a :SERial (see page 160) <return value> ::= unquoted
string containing serial number
:SINGle (see page 161) n/a n/a
n/a :STATus? <display>
(see page 162)
{0 | 1}
<display> ::= {CHANnel<n> |
FUNCtion | MATH | FFT |
WMEMory<r> | ABUS}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
:STOP (see page 163) n/a n/a
Table 3 Root (:) Commands Summary (continued)
Command Query Options and Query Returns
