Keysight Technologies InfiniiVision DSOX1204G

56 Keysight InfiniiVision DSOX1204A/G Oscilloscopes Programmer's Guide
4 Commands Quick Reference
n/a :TER? (see page 164) {0 | 1}
:VIEW <source> (see
page 165)
n/a <source> ::= {CHANnel<n> |
FUNCtion | MATH | WMEMory<r>}
<n> ::= 1 to (# analog channels)
in NR1 format
<r> ::= 1 to (# ref waveforms) in
NR1 format
Table 3 Root (:) Commands Summary (continued)
Command Query Options and Query Returns
Table 4 :ABUS Commands Summary
Command Query Options and Query Returns
:ABUS:BIT<m> {{0 |
OFF} | {1 | ON}} (see
page 169)
:ABUS:BIT<m>? (see
page 169)
{0 | 1}
<m> ::= 0-3; an integer in NR1
format
:ABUS:BITS
<channel_list>, {{0 |
OFF} | {1 | ON}} (see
page 170)
:ABUS:BITS? (see
page 170)
<channel_list>, {0 | 1}
<channel_list> ::= (@<m>,<m>:<m>
...) where "," is separator and
":" is range
<m> ::= 0-3; an integer in NR1
format
:ABUS:CLEar (see
page 172)
n/a n/a
:ABUS:DISPlay {{0 |
OFF} | {1 | ON}} (see
page 173)
:ABUS:DISPlay? (see
page 173)
{0 | 1}
:ABUS:LABel <string>
(see page 174)
:ABUS:LABel? (see
page 174)
<string> ::= quoted ASCII string
up to 10 characters
:ABUS:MASK <mask>
(see page 175)
:ABUS:MASK? (see
page 175)
<mask> ::= 32-bit integer in
decimal, <nondecimal>, or
<string>
<nondecimal> ::= #Hnn...n where n
::= {0,..,9 | A,..,F} for
hexadecimal
<nondecimal> ::= #Bnn...n where n
::= {0 | 1} for binary
<string> ::= "0xnn...n" where n
::= {0,..,9 | A,..,F} for
hexadecimal
