Barco Event Master E2 Series User Manual

R5905948 /12 Event Master Devices376
After that it becomes more of a modifier with other buttons.
PVW Trans
Image 12-25
Currently selected layers in Preview will preview its Key Frame effect (move) without showing on program.
Capture Still
Image 12-26
With the Capture Still Button a Still Store can be captured via syntax. Declare the source file number to direct
the capture process on the desired live source.
Syntax:
• SOURCE # Capture Still ENTER
Barco Eye
Image 12-27
The Barco Eye button works as a Modifier Button, like Windows/CTRL/Fn button on a keyboard. This is
further described in functionality around other buttons.
Mod PGM (Modify Program) [Red button cap]
Image 12-28
Pressing button Unlocks Selected Destinations Program for Edit just as clicking the small lock in Program.
Red LED indicates active.
Live [Red button cap]
Image 12-29
The Live button latches and Red LED indicates active.
When the live function is active the Assign Key Source BUS or the Syntax actions regarding LAYERS/
SOURCE/PRESET/USER KEY are applied in the PROGRAM as opposed to the normal PREVIEW BUS.
LAYER
Layer Selection is made on PROGRAM.
SOURCE
Controller Operation
