CES-128 voice encryp
tor option
284
Manpack T
ransceive
r 21
10
series Reference Manual
Erasing all of the CES secure keys
All of the secure keys in the Corporate secu
re indexes in the tran
sceiver may be erased
via a simple hot-key sequence.
T
o erase all secure keys:
1
Press
+
SEC
.
1
Hold
.
NOTE
If you want to disable this hot-key sequence see
page
481,
Contr
olling
access to erasing secur
e keys
.
NOTE
The Base secure key in secure index 0 is not erased.
299
301
