AES-256 digital data encryptor option
324
Manpack T
ransceive
r 21
10
series Reference Manual
Erasing all of the AES secure keys
All of the secure keys in the transceiver
may be erased via a simple hot-key sequence.
T
o erase all secure keys:
1
Press
+
SEC
.
1
Hold
.
NOTE
If you want to disable this hot-key sequence see
page
481,
Contr
olling
access to erasing secur
e keys
.
NOTE
If a voice encryptor option is also in
stalled, you are asked if you want to
Erase Vce&Dat
a Keys
.
339
341
