9-1

9 Accessing the Inside of the

Warming Unit

9.1 Overview

This chapter provides instructions for accessing components inside the Covid-

ien WarmTouch™ Convective Warming Unit.

 Note:

Testing is required after service procedures that involve accessing the inside of the

warming unit. Refer to the instructions in each component replacement section for

minimum testing requirements.

9.2 Safety Reminders

 WARNING:

No modification of this equipment is allowed. Modification can result in

death, injury, or property damage.

 WARNING:

Before attempting to open or disassemble the warming unit, disconnect the

power cord from the AC power source.

 Caution:

Observe ESD (electrostatic discharge) precautions when servicing the

warming unit.
