Ground Cable Replacement
Service Manual 10-49
 WARNING:
Disconnect the warming unit's power cord from the AC power source before
performing this procedure.
To replace the ground cable:
1. Follow the procedure Separating the Front and Rear Enclosures on page 9-2.
2. Disconnect the ground cable from the GND terminal on the power supply
(Figure 10-35 on page 10-48).
3. Disconnect the ground cable from the equipotential stud as follows (Figure 10-
36):
a. Remove the top nut from the threaded end of the stud.
b. Remove the lock washer.
c. Lift the ground cable terminal off the stud.
Figure10-36.Ground Cable Terminal on Equipotential Stud
