Power PCBA Replacement

Service Manual 10-31

10.9 Power PCBA Replacement

The Power PCBA requires proper disposal in accordance with WEEE Directive.

Do not dispose of this item as unsorted municipal waste.

Figure10-24.Power PCBA

Requirements:

• WT-CWU Power PCBA Kit (page A-3)

• Torque driver with #2 Phillips bit

 WARNING:

Disconnect the warming unit's power cord from the AC power source before

performing this procedure.
