8-1

8 External Component Replacement

8.1 Overview

This chapter provides instructions for replacing external components of the

Covidien WarmTouch™ Convective Warming Unit.

8.2 Safety Reminders

 WARNING:

No modification of this equipment is allowed. Modification can result in

death, injury, or property damage.

 WARNING:

Before attempting to open or disassemble the warming unit, disconnect the

power cord from the AC power source.

 Caution:

Observe ESD (electrostatic discharge) precautions when servicing the

warming unit.

Pole Clamp Replacement Page 8-2

USB Port Cover Replacement Page 8-4

Power Cord Replacement Page 8-5

Nozzle Replacement Page 8-8

Nozzle Strap with Clip Replacement Page 8-10

No Free-Hosing Label Replacement Page 8-11
