Internal Component Replacement (Inside Rear Enclosure)

11-14 Service Manual

11.5 Thermostat Cable Replacement

Figure11-13.Thermostat Cable

Requirements:

• WT-CWU Thermostat Cable Kit (page A-5)

• Torque driver with #2 Phillips bit

• Wire cutters

• 2 cable ties

1 Thermostat Cable Connection

(to Thermostat)

3 Thermostat Cable Routing Tabs

2 Thermostat Cable 4 Thermostat Cable Connection

(Power PCBA)
