A Parts and Accessories

A.1 Overview

This appendix describes the parts and accessories available for the Covidien

WarmTouch™ Convective Warming Unit. Most spare parts are available as kits

containing all components necessary for replacement.

To order parts and accessories, contact Covidien Technical Services or your

local Covidien representative. Reference Obtaining Technical Assistance on

page 1-14.

External Components Page A-2

Internal Components (Inside Front Enclosure) Page A-3

Internal Components (Inside Rear Enclosure) Page A-5

Enclosures Page A-6

Miscellaneous Components Page A-7

Parts Locator Page A-8
