7-1

7 Performance Verification

7.1 Overview

This chapter provides instructions for testing the Covidien WarmTouch™ Con-

vective Warming Unit after repair. Testing is required after most service proce-

dures. Refer to the instructions in each component replacement section for

minimum testing requirements.

7.2 Safety Reminders

 WARNING:

Possible electric shock hazard. Grounding reliability can be achieved only

when the warming unit is connected to a suitable mains outlet with

protective earth grounding.

 Caution:

Observe ESD (electrostatic discharge) precautions when servicing the

warming unit.

Required Test Equipment Page 7-2

Service Screen Access Page 7-2

Performance Tests Page 7-3

Electrical Safety Tests Page 7-14
