Internal Components (Inside Front Enclosure)
Service Manual A-3
A.3 Internal Components (Inside Front Enclosure)
TableA-2.Parts List – Internal Components (Inside Front Enclosure)
Kit or Part Part
Number
Figure Procedure
WT-CWU Keypad Kit
1 - Keypad, WarmTouch
10088294 Figure A-1
Figure A-5
Page 10-3
WT-CWU Display Kit
1 - TFT Display, 2.5", QVGA, 320x240, 350 NITS, 80/
80/80/80 View Ang
1 - Foam, Non-conductive, 1 Side PSA (attached to
back of display)
2 - Washer, Shoulder, Nylon
2 - Nut, 8-32, Machine Screw, Hex
2 - Washer, Lock, #8, Ext. Tooth
2 - Washer, #8,Flat, Nylon
10088292 Figure A-5 Page 10-8
WT-CWU UI PCBA Kit
1 - PCB Assembly, UI, WarmTouch
1 - Backing Plate, USB Connector
2 - Washer, Shoulder, Nylon
2 - Nut, 8-32, Machine Screw, Hex
2 - Washer, Lock, #8, Ext. Tooth
2 - Washer, #8,Flat, Nylon
10088293 Figure A-5 Page 10-12
WT-CWU Ribbon Cable Kit
1 - Cable Assembly, Ribbon, 20 Pos, .050" Pitch
GR103059 Figure A-5 Page 10-19
WT-CWU USB Micro AB Cable Kit
1 - Cable Assembly, USB Micro AB
2 - Machine Screw #4-40 x 3/8” PH PAN HD LG
GR103063 Figure A-5
Figure A-6
Page 10-22
WT-CWU Power PCBA Kit
1 - PCB Assembly, Power, WarmTouch
4 - Screw #6 x 7/16",Plastite, PH HD,SS
10088295 Figure A-6 Page 10-31
WT-CWU Fuse Kit
5 - Fuse, Glass, 10A, 250V, 5 x 20mm
10092815 Figure A-5 Page 10-35
WT-CWU Speaker Kit
1 - Speaker, 8 Ohm, 2.5"Sq x 1.16" H, 10 dB Max
4 - Screw #6 x 7/16",Plastite, PH HD,SS
10088296 Figure A-5 Page 10-37
