Parts and Accessories
A-4 Service Manual
WT-CWU Speaker Cable Kit
1 - Wire Assembly, Speaker
GR103061 Figure A-5 Page 10-40
WT-CWU Pwr Supply Kit
1 - AC/DC Converter, 90-264VAC, 65W, 48VDC
Output
4 - Screw #4 x .38 Lg, Plastite, PH PAN HD
10088291 Figure A-5 Page 10-43
WT-CWU P/S Output Cable Kit
1 - Wire Assembly, Output AC/DC Converter
GR103060 Figure A-5 Page 10-46
WT-CWU Ground Cable Kit
1 - Wire Assembly, Ground
GR103064 Figure A-5 Page 10-48
WT-CWU AC Inlet Kit
1 - Wire assembly, AC inlet
2 - Screw #4 x.5 LG, Plastite,PH PAN HD
10088288 Figure A-5 Page 10-51
WT-CWU Equipotential Stud Kit
1 - Washer, Color Code
2 - Washer, Lock External, M6
2 - Hex Nut, M6 Thin, Stainless Steel
1 - Pin, Equipotential
10088290 Figure A-3
Figure A-5
Page 10-55
TableA-2.Parts List – Internal Components (Inside Front Enclosure) (Continued)
Kit or Part Part
Number
Figure Procedure
