Covidien WarmTouch - Figure 11-32 Filter Enclosure and Screws

To Next Page

To Previous Page

Fan Assembly Replacement

Service Manual 11-35

d. Set the filter enclosure (with power cord attached), filter, and screws aside.

Figure11-32.Filter Enclosure and Screws

4. Follow the procedure Separating the Front and Rear Enclosures on page 9-2.

1 Filter Enclosure 3 Power Cord Routing Bracket

2 Filter Enclosure Screws (x3)
