Covidien WarmTouch - B Error Codes; B.1 Overview

To Next Page

To Previous Page

B-1

B Error Codes

B.1 Overview

This appendix defines the error codes that may be generated during operation

of the Covidien WarmTouch™ Convective Warming Unit. You can view the

most recent error codes on the System Information screen. See Serial Number,

Software Version, and Error Codes on page 1-9.

Suggested resolutions are provided for each error. If an error situation cannot

be resolved, or if you see an error code that is not listed, contact Covidien Tech-

nical Services. See Obtaining Technical Assistance on page 1-14.
