Covidien WarmTouch - 7.5.3 Display Test

To Next Page

To Previous Page

Performance Tests

Service Manual 7-7

7.5.3 Display Test

Use the display test to confirm that there are no bad pixels.

To perform the display test:

1. Plug the warming unit’s power cord into the outlet, and press the On/Standby

key.

2. Verify that the initial display screen is lighted white and has no vertical or

horizontal black or colored rows.

3. When finished with all testing:

a. Press the On/Standby key to power off the unit.

b. Unplug the unit from the outlet.

Display Test Failure

If the test fails, see Basic Troubleshooting on page 6-9.
