Introduction

1-6 Service Manual

 WARNING:

Possible electrical shock hazard. To reduce the risk of electrical shock, do not

remove the back case. Servicing is only to be done by qualified personnel.

1.2.5 Cautions (Patient Treatment)

The following additional Cautions apply to operating the warming system in a

clinical environment for patient treatment:

 Caution:

Federal (U.S.A.) law restricts the use of the warming system to sale by or on

the order of a physician.

 Caution:

Only use WarmTouch™ blankets with the WarmTouch warming unit. Do not

attempt to use other types of blankets with the warming unit. Similarly, do

not attempt to use WarmTouch blankets with other types of warming units.

 Caution:

The USB port on the warming unit is for service use by qualified personnel

only. During patient treatment, a USB cable must not

be connected to the

warming unit.
