6 Troubleshooting

6.1 Overview

This chapter provides information for troubleshooting problems that may

occur with the Covidien WarmTouch™ Convective Warming Unit.

6.2 Safety Reminders

 WARNING:

No modification of this equipment is allowed. Modification can result in

death, injury, or property damage.

 Caution:

Operation of the warming system may affect or be affected by other devices

in the vicinity due to electromagnetic interference (EMI). If interference

occurs, try increasing the distance between devices, repositioning the cabling,

or plugging the devices into separate outlet circuit branches. Reference

Electromagnetic Compatibility (EMC) on page 13-4 for additional guidance.

Principles of Operation Page 6-2

Basic Troubleshooting Page 6-9

Alarms Page 6-12
