4 Operation

4.1 Overview

This chapter provides basic operating instructions for the Covidien Warm-

Touch™ Convective Warming Unit. Full instructions for operating the unit in a

clinical setting are provided in the Covidien WarmTouch™ Convective

Warming System Operator’s Manual. Clinicians intending to use the warming

system for treatment of patients must consult the Operator’s Manual.

4.2 Safety Reminder

 WARNING:

The use of accessories or cables with the warming system other than those

indicated in this manual may result in non-compliance with the specifications

listed in Electromagnetic Compatibility (EMC) on page 13-4.

Applying Power Page 4-2

Overview of Warming Unit Operating Modes Page 4-3

Beginning Operation Page 4-4

Controlling the Temperature Page 4-5

Powering Off the Warming Unit Page 4-8
