Miscellaneous Components
Service Manual A-7
A.6 Miscellaneous Components
TableA-5.Parts List – Miscellaneous Components
Kit or Part Part
Number
Figure Procedure
WT-CWU Hardware Kit
25 - Screw #6 x 7/16",Plastite, PH HD,SS
10 - Screw, #8 x .50, Plastite, PH HD
10 - Screw 8-32 x .38,Truss HD,ST Zinc
10 - Screw #4 x .38 Lg, Plastite, PH PAN HD
10 - Machine Screw #4-40 x 3/8” PH PAN HD LG
5 - Pop Rivet, Plastic, 0.126-0.138
5 - Backing Plate, USB Connector
10 - Rivet, Plastic
10 - Washer, Shoulder, Nylon
10 - Nut, 8-32, Machine Screw, Hex
10 - Washer, Lock, #8, Ext. Tooth
10 - Screw #4 x .5 Lg, Plastite, PH PAN HD
10 - Washer, #8,Flat, Nylon
10 - Screw, #6 x .38" Long, Sht Metal T-A,ST Zinc
10088289 N/A N/A
WT HEPA Filter Kit
1 - Filter, HEPA
1 - Gasket with Adhesive, WarmTouch
3 - Screw, #8 x .50, Plastite, PH HD
10092812 FigureA-4 Page5-4
Transport Cart 5022900 N/A Page 3-9
Operator’s Manual - Covidien WarmTouch™
Convective Warming System
10077305 N/A N/A
