Covidien WarmTouch

To Next Page

To Previous Page

Error Codes

B-8 Service Manual

049

Category: A/D

Alarm Priority: Low

Description: Fan voltage < 10 V.

Resolution: Replace the power PCBA. See page 10-31.

051

Category: A/D

Alarm Priority: Low

Description: Thermistor values not changing.

Resolution: Replace the power PCBA. See page 10-31.

053

Category: A/D

Alarm Priority: Low

Description: No edges detected on AC_STATUS signal.

Resolution: N/A - Indicates that the power cord was disconnected while the unit was still

powered on.

131

Category: POST

Alarm Priority: Low

Description: RAM check error during POST.

Resolution: Replace the UI PCBA. See page 10-12.
