Covidien WarmTouch

To Next Page

To Previous Page

Error Codes

B-10 Service Manual

144

Category: POST

Alarm Priority: Low

Description: UI calculated checkword does not match the stored checkword.

Resolution: Replace the UI PCBA. See page 10-12.

145

Category: POST

Alarm Priority: Low

Description: GPX calculated checkword does not match the stored checkword.

Resolution: Replace the UI PCBA. See page 10-12.

152

Category: UI

Alarm Priority: Low

Description: External watchdog timed out.

Resolution: Replace the UI PCBA. See page 10-12.

157

Category: UI

Alarm Priority: Medium

Description: Thermostat open.

Resolution: Check for:

• Thermistor dislodged from hose duct adapter - See page 11-3.

If the thermistor is in position, replace the power PCBA. See page 10-31.
