Error Codes

B-12 Service Manual

165

Category: UI

Alarm Priority: Low

Description: No communication from AD microprocessor.

Resolution: Replace the power PCBA. See page 10-31.

175

Category: UI

Alarm Priority: Low

Description: Software upgrade cannot proceed due to checkword check error. Software file

may be corrupted.

Resolution: Obtain new software file(s) and retry the upgrade.

176

Category: UI

Alarm Priority: Low

Description: Software upgrade cannot proceed due to header check error. Software file may

be corrupted or invalid.

Resolution: Obtain new software file(s) and retry the upgrade.

177

Category: UI

Alarm Priority: Low

Description: The UI microprocessor received a message from the A/D microprocessor indicating

that the heater and fan were shut down. Cause is typically provided in subsequent

error messages.

Resolution: N/A - Refer to subsequent error messages.
