FOR-A FA-9520 - Page 166

166
 Antialias
Parameter
Default
Setting range
(Steps)
Description
Horizontal
Normal
Weak 8-1
Normal
Strong1-8
Performs horizontal anti-aliasing for the
output video image.
Weak 8 to Strong 8 (low to high)
This setting cannot be changed if the
conversion is set to the formats indicated as
(BYPASS) in the CONV Conversion Table in
section 5-3-2.
Vertical
Normal
Weak 8-1
Normal
Strong1-8
Performs vertical anti-aliasing for the output
video image.
Weak 8 to Strong 8 (low to high)
This setting cannot be changed if the
conversion is set to the formats indicated as
(BYPASS) in the CONV Conversion Table in
section 5-3-2.
The Antialias setting cannot be changed if Converter Process Mode is set to BY-PASS, or if
the conversion is set to the formats indicated as (BY-PASS) in the CONV Conversion Table
(5-3-2).
 Enhance
Parameter
Default
Setting range
(Steps)
Description
Enhance
Level 0
Level 0-8
Sharpens the output video image.
Level 0 to 8 (low to high)
The Enhance setting cannot be changed if Converter Process Mode is set to BY-PASS.
Also, it cannot be changed if the conversion is set to the formats indicated as (BY-PASS) in
the CONV Conversion Table (5-3-2).
 Converter, Size
Parameter
Default
Setting range(Steps)
Description
H Size
(Horizontal Size)
100.0％
50.0 - 150.0%
(0.1%)
Adjusts the width of the video
displayed on the monitor.
V Size
(Vertical Size)
100.0％
50.0 - 150.0%
(0.1%)
Adjusts the height of the video
displayed on the monitor.
The Converter Size setting cannot be changed if Converter Process Mode is set to BY-PASS.
Also, it cannot be changed if the conversion is set to the formats indicated as (BY-PASS) in
the CONV Conversion Table (5-3-2).
 Converter, Position
Parameter
Default
Setting range (Steps)
Description
H Position
(Horizontal Position)
0 Pixel
Variable
*1
(2 Pixel)
Adjusts the horizontal position of
the video displayed on the monitor.
V Position
(Vertical Position)
0 Line
Variable
*1
(1 Line)
Adjusts the vertical position of the
video displayed on the monitor.
The Converter Position setting cannot be changed if Converter Process Mode is set to
BY-PASS. Also, it cannot be changed if the conversion is set to the formats indicated as
(BY-PASS) in the CONV Conversion Table (5-3-2).
*1 The Converter Position setting range varies depending on Converter Process Mode, and
Sync Format settings in FS Mode (9-4-1 FS1/FS2 Video System).
