FOR-A FA-9520 - Page 167

167
 Converter, Crop
Parameter
Default
Setting range (Steps)
Description
H Left
0 Pixel
Variable
*1
(2 Pixel)
Crops the left side of the video.
H Right
0 Pixel
Variable
*1
(2 Pixel)
Crops the right side of the video.
V Top
0 Line
Variable
*1
(1 Line)
Crops the top of the video.
V Bottom
0 Line
Variable
*1
(1 Line)
Crops the bottom of the video.
The Converter Crop setting cannot be changed if Converter Process Mode is set to BY-PASS.
Also, it cannot be changed if the conversion is set to the formats indicated as (BY-PASS) in
the CONV Conversion Table (5-3-2).
*1 The Converter Crop setting range varies depending on the Sync Format settings in FS
Mode (9-4-1 FS1/FS2 Video System).
IMPORTANT
The cropping setting range resets itself if the video input changes. If the set value
exceeds the setting range due to an input change, the set value will automatically
reset itself to the default value. If the set value exceeds the horizontal range, the H Left
and H Right settings will reset to their default values. If the value exceeds the vertical
range, the V Top and V Bottom settings will also reset accordingly.
 Side Cut Color
Parameter
Default
Setting range
Description
Red, Green, Blue
0
0 - 255
Sets background color that will be visible if the
converted image is set smaller than the original
under Converter1 Size (5-3-3).
R, G, and B components can be adjusted
separately.
Control knob F4 allows you to adjust R, G, and
B at the same time.
The Side Cut Color setting cannot be changed if Converter Process Mode is set to BY-PASS.
Also, it cannot be changed if the conversion is set to the formats indicated as (BY-PASS) in
the CONV Conversion Table (5-3-2).
