Icom IC-7100 Advanced Instructions

5
FUNCTIONS FOR RECEIVE
5-9
NR
Noise Reduction
The Noise Reduction function reduces random noise
components and enhances audio signals which are
buried in noise. The received signals are converted to
digital signals and then the audio signals are separated
from the noise.
Push q
NR
(C) to turn ON the Noise Reduction.
• “NR” appears.
Hold down w
NR
(C) for 1 second to display the “NR”
screen (Noise Reduction).
Rotate the Dial e to adjust the Noise Reduction level;
rotate it clockwise to higher reduction level or coun-
ter clockwise to lower reduction level.
• If desired, touch [DEF](D) for 1 second to reset to the
default setting.
• The adjustable reduction level is between 1 and 15.
Push r
NR
(C) to exit the “NR” screen (Noise Reduc-
tion) .
• If desired, push
NR
(C) to turn OFF the Noise Reduc-
tion.
A large rotation of the “NR control” results in audio
signal masking or distortion. Set the “NR control” for
maximum readability.
Noise reduction ONNoise reduction OFF
Desired
signal (CW)
Noise components
L
eft
R
ight
C
enter
D
isplay
The L, R, C or D in the
instructions indicate the
part of the controller.
L: Left side
R: Right side
C: Center bottom
D: Display (Touch screen)
NR icon
Touch for 1 second
to reset to default
Previous view

Icom IC-7100 Specifications

General

Supply	13.8 V DC ±15%
Voltage	13.8 V DC
Operating Temperature	-10°C to +60°C
Frequency Coverage	0.030-199.999 MHz, 400-470 MHz
Modes	SSB, CW, AM, FM, DV
Output Power	HF/50MHz: 100W, 144MHz: 50W, 430MHz: 35W
Receiver Type	Superheterodyne
Antenna Connector	SO-239 (HF/50MHz/144MHz), N-type (430MHz)
Weight	Main unit: 2.3 kg
Type	Base/Mobile
Frequency Range TX	1.8–54 MHz, 144–148 MHz, 430–450 MHz
Frequency Range RX	0.030–199.999 MHz, 400–470 MHz
Memories	505
Current Consumption	TX: 22 A, RX: 1.2 A
