Icom IC-7100

9
D-STAR OPERATION <ADVANCED>
9-26
Touch “Edit”
Touch [CS]
Edit the Call
sign, then
touch [ENT].
Touch “R1:”
for 1 second
D For Duplex (repeater) operation
While in the DR mode, only “MY” call sign can be set.
Example :
While in the DV mode, Making a Gateway call
Making a gateway CQ call to Hamacho repeater (JP1Y-
IU B) from the Hirano repeater (JP3YHH B)*, while in
the DV mode.
* Before starting to set the call sign, set the frequency of your
access repeater or duplex setting. (See Section 3.)
Call sign “R1” setting1.
Select any other than DR mode. q
(Example: Memory mode)
Push w
MENU
(C) one or more times to select the
“M-2” screen (M-2 menu).
Touch [CS]( e D) to enter the “CALL SIGN” screen.
Touch “R1:” for 1 second. r
• The function window is displayed.
• Rotate the Dial to select “R1:,” and then push
QUICK
(C)
also opens the function window.
t Touch “Edit” to enter the “RPT1 CALL SIGN” (Edit)
screen.
Touch the desired block one or more times to select y
the desired character or symbol. (Example: J)
Selectable characters and symbols
A to Z, 0 to 9, ⁄ and (space)
• Touch “AB⇔12” to toggle between the Alphabet input
and Number input mode.
• Touch [CLR](D) to delete the selected character, symbol
or number.
• Touch “  ” to input a space.
Touch [ u f](D) to move the cursor backwards, or
touch [g](D) to move the cursor forwards.
Repeat steps i y and u to enter up to 8 characters,
including spaces, and then touch [ENT](D).
( Example: First, J, then P, then 3, then Y, then H, then
H.)
• The display returns to the “CALL SIGN” screen.
The L, R, C or D in the in-
structions indicate the part
of the controller.
L: Left side
R: Right side
C: Center bottom
D: Display (Touch screen)
L
eft
R
ight
C
enter
D
isplay
Changing the Call sign setting (Continued)
