Icom IC-7100

9
D-STAR OPERATION <ADVANCED>
9-23
D Digital code setting
Push q
DR
(C) to enter the DR mode.
Push w
MENU
(C) to select the “D-2” screen (D-2
menu).
• To use the digital code squelch function in another mode,
push
MENU
(C) to select the “M-2” screen (M-2 menu).
Touch [DSQL]( e D) for 1 second to display the “DSQL”
screen.
Rotate the Dial to adjust the digital code. r
• If desired, touch [DEF](D) for 1 second to reset to the
default setting.
• When the received signal’s code does not match, the
digital code squelch does not open; however, the S/RF
meter shows the received signal strength.
Digital squelch function (Continued)
A total of 100 codes (00–99)
are selectable.
The L, R, C or D in the
instructions indicate the
part of the controller.
L: Left side
R: Right side
C: Center bottom
D: Display (Touch screen)
L
eft
R
ight
C
enter
D
isplay
Touch [DSQL]
for 1 second.
Rotate
the Dial
.
