17
SET MODE
17-21
MAIN DIAL Auto TS (Default: HIGH)
Function > MAIN DIAL Auto TS (MAIN DIAL Auto TS)
Set the Auto Tuning Step function for the Dial.
When rapidly rotating the Dial, the tuning step auto-
matically changes as selected.
There are two types of auto tuning steps: LOW (Faster)
and HIGH (Fastest).
• OFF: Auto tuning step is turned OFF.
• LOW: Approximately 2 times faster.
• HIGH: Approximately 5 times faster when the tuning
step is set to 1 kHz or smaller steps; approxi-
mately 2 times faster when the tuning step is
set to 5 kHz or larger steps.
MIC Up/Down Speed (Default: Fast)
Function > MIC Up/Down Speed (MIC Up/Down
Speed)
Set the microphone [∫]/[√] switches speed while hold-
ing down.
• Slow: Low speed (25 tuning steps/second)
• Fast: High speed (50 tuning steps/second)
[NOTCH] Switch (SSB) (Default: Auto/Manual)
Function > [NOTCH] Switch (SSB) ([NOTCH] Switch
(SSB))
Select the Auto, Manual or Auto/Manual notch filter to
be used for SSB mode operation.
• Auto: Only the Auto notch lter can be used.
• Manual: Only the Manual notch lter can be
used.
• Auto/Manual: Both the Auto and Manual notch lters
can be used.
[NOTCH] Switch (AM) (Default: Auto/Manual)
Function > [NOTCH] Switch (AM) ([NOTCH] Switch
(AM))
Select the Auto, Manual or Auto/Manual notch filter to
be used for AM mode operation.
• Auto: Only the Auto notch lter can be used.
• Manual: Only the Manual notch lter can be
used.
• Auto/Manual: Both the Auto and Manual notch lters
can be used.
SSB/CW Sync Tuning (Default: OFF)
Function > SSB/CW Sync Tuning (SSB/CW Sync Tun-
ing)
Turn the displayed frequency shift function ON or OFF.
When this function is turned ON, the audio pitch or
tones of the received signal will remain the same, even
when the operating mode is changed between SSB
and CW.
The amount of frequency shift may differ, depending on
the CW pitch setting.
• OFF: The displayed frequency does not shift.
• ON: The displayed frequency shifts when the operat-
ing mode is changed between SSB and CW.
CW Normal Side (Default: LSB)
Function > CW Normal Side (CW Normal Side)
Select the sideband used to receive CW in the CW nor-
mal mode between LSB and USB.
VOICE 1st Menu (Default: VOICE-TX)
Function > VOICE 1st Menu (VOICE 1st Menu)
Select VOICE-Root or VOICE-TX as the menu that ap-
pears first after touching [VOICE] in the “M2” screen
(Menu 2), when the SSB, AM, FM or DV mode is se-
lected.
• VOICE-Root: The voice menu appears rst.
• VOICE-TX: The voice SEND menu appears rst.
KEYER 1st Menu (Default: KEYER-SEND)
Function > KEYER 1st Menu (KEYER 1st Menu)
Select KEYER-Root or KEYER-SEND as the menu
that appears first after touching [KEYER] in the “M2”
screen (Menu 2), when in the CW mode.
• KEYER-Root: The Memory keyer menu appears
first.
• KEYER-SEND: The Keyer SEND menu appears rst.
Speaker Out (Default: ON)
Function > Speaker Out (Speaker Out)
Select the speaker output function.
• OFF: The speaker does not output the received au-
dio.
The [ACC] socket, [USB] port, and [MIC] con-
nector output the received audio.
• ON: The speaker outputs the received audio.
Function Set mode (Continued)
