Icom IC-7100 Advanced Instructions

11
MEMORY OPERATION
11-12
While in the memory mode, the programmed memory
name can be displayed.
Touch the Memory channel number indication once q
or twice to select the Memory mode. (p. 3-4)
Push w
QUICK
(D) to open the Quick Menu window.
Touch [Name Display]. e
Touch the desired Display type option. r
• OFF: Displays only the frequency.
• ON: Displays the memory name under the fre-
quency. (Default)
Push
QUICK
.
Touch
[Name Display].
Touch “OFF.”
The memory name
disappears.
Selecting a Memory display type
The L, R, C or D in the
instructions indicate the
part of the controller.
L: Left side
R: Right side
C: Center bottom
D: Display (Touch screen)
L
eft
R
ight
C
enter
D
isplay
Previous view

Icom IC-7100 Specifications

General

Supply	13.8 V DC ±15%
Voltage	13.8 V DC
Operating Temperature	-10°C to +60°C
Frequency Coverage	0.030-199.999 MHz, 400-470 MHz
Modes	SSB, CW, AM, FM, DV
Output Power	HF/50MHz: 100W, 144MHz: 50W, 430MHz: 35W
Receiver Type	Superheterodyne
Antenna Connector	SO-239 (HF/50MHz/144MHz), N-type (430MHz)
Weight	Main unit: 2.3 kg
Type	Base/Mobile
Frequency Range TX	1.8–54 MHz, 144–148 MHz, 430–450 MHz
Frequency Range RX	0.030–199.999 MHz, 400–470 MHz
Memories	505
Current Consumption	TX: 22 A, RX: 1.2 A
