Icom IC-7100

9
D-STAR OPERATION <ADVANCED>
9-10
EMR communication
The EMR (Enhanced Monitor Request) communication
mode can be used in only the DV mode. In the EMR
mode, no call sign setting is necessary.
All transceivers that receive an EMR mode signal auto-
matically open their squelch to receive the signal.
When an EMR mode signal is received, the audio (voice)
will be heard at the specified level, even if the volume
setting level is set to the minimum level, or digital call
sign/digital code squelch is in use. (Default: OFF)
NOTE: The EMR communication function is auto-
matically turned OFF when the transceiver is turned
OFF.
Push q
DR
(C) to enter the DR mode.
• The DR mode is selected.
Touch the “FROM” field. w
• The “FROM SELECT” screen appears.
Touch “Repeater List.” e
• The “REPEATER GROUP” screen appears.
Touch the repeater group where your access repeat- r
er is listed.
• Example: “11: Japan”
Touch your access repeater. t
• Example: “Hamacho”
• “Hamacho” is displayed in “FROM.”
Push y
SET
(C) to enter the Set mode.
Touch the “EMR” item of the DV SET Set mode. u
DV Set > EMR
• If the specied item is not displayed, touch [∫] or [√](D)
one or more times to select the page.
Touch “ON.” i
Push o
SET
(C) to exit the Set mode.
• “EMR” appears.
!0 Push [PTT] on the microphone or switch ON the ex-
ternal TX switch to transmit.
• The TX/RX indicator lights red.
• “EMR” blinks on a station that receives the EMR signal.
The audio (voice) will be heard at the specified level, or
the [AF]
(L) control level, whichever is higher.
!1 Release [PTT] or Switch OFF the external TX switch
to receive.
!2 To cancel the EMR mode, select “OFF” in step i, as
described above, or turn OFF the power.
Appears
Example: To transmit from the “Hamacho” repeater in
the EMR mode
The L, R, C or D in the
instructions indicate the
part of the controller.
L: Left side
R: Right side
C: Center bottom
D: Display (Touch screen)
L
eft
R
ight
C
enter
D
isplay
Touch
“DV Set”
Touch
“EMR”
Touch
“ON”
Push
SET
