Icom IC-7100

13
USING AN SD CARD
13-4
Turn OFF the transceiver. q
Insert the card into the slot until it locks in place, and w
makes a ‘click’ sound.
• “ ” appears when the SD card is inserted.
• “
” and “ ” alternately blink while accessing the SD
card.
NOTE: Before inserting, be sure to check the card
direction.
If the card is forcibly or inversely inserted, it will dam-
age the card and/or the slot.
Inserting the SD card
Terminals
facing down
Cut corner side
Front
panel
SD card
Appears
●
w
q
q
D Formatting the SD card
• If you use a brand new SD card, format it, by doing
the following steps.
• Formatting a card erases all its data. Before for-
matting any programmed card, make a backup file
onto your PC.
Turn OFF the transceiver, and then insert the card q
into the slot.
Turn ON the transceiver. w
• “ ” appears when the SD card is inserted.
Push e
SET
(C) to enter the Set mode.
Touch the “SD Card” Set mode. r
• If the specied item is not displayed, touch [∫] or [√](D)
one or more times to select the page.
Touch the “Format” item. t
• The conrmation screen “Format OK?” appears.
Touch [YES]( y D).
• The formatting starts and the display shows the format-
ting progress.
• After formatting ends, the display automatically returns to
the screen displayed before touching [YES](D).
The L, R, C or D in the
instructions indicate the
part of the controller.
L: Left side
R: Right side
C: Center bottom
D: Display (Touch screen)
L
eft
R
ight
C
enter
D
isplay
