Icom IC-7100 Advanced Instructions

15
VOICE TX FUNCTION
15-3
Playing back the recorded voice audio
The recorded voice audio for the Voice TX function can
be played back.
Push q
MENU
(C) one or more times to select the “M-
2” (Menu 2) screen.
• In the DR mode, select the “D1” screen.
Touch [VOICE]( w D) to select the Voice TX mode.
• The “VOICE TX” screen is displayed.
Push e
MENU
(C) to display the “VOICE” screen.
Touch [REC]( r D) to display the “VOICE TX RECORD”
screen.
Touch the desired memory, [T1] through [T4]. t
• The “VOICE TX RECORD (T1)” screen is displayed,
when [T1] memory is selected.
Touch [ y ≈](D) to start the playback.
• Touch [■](D) to stop the playback.
Touch [ u ](D) to return to the “VOICE TX RECORD”
screen.
Touch
[VOICE]
Touch [REC]
(Example)
Touch [T1]
Push
MENU
Touch [≈]
While playing
The L, R, C or D in the
instructions indicate the
part of the controller.
L: Left side
R: Right side
C: Center bottom
D: Display (Touch screen)
L
eft
R
ight
C
enter
D
isplay
Previous view

Icom IC-7100 Specifications

General

Supply	13.8 V DC ±15%
Voltage	13.8 V DC
Operating Temperature	-10°C to +60°C
Frequency Coverage	0.030-199.999 MHz, 400-470 MHz
Modes	SSB, CW, AM, FM, DV
Output Power	HF/50MHz: 100W, 144MHz: 50W, 430MHz: 35W
Receiver Type	Superheterodyne
Antenna Connector	SO-239 (HF/50MHz/144MHz), N-type (430MHz)
Weight	Main unit: 2.3 kg
Type	Base/Mobile
Frequency Range TX	1.8–54 MHz, 144–148 MHz, 430–450 MHz
Frequency Range RX	0.030–199.999 MHz, 400–470 MHz
Memories	505
Current Consumption	TX: 22 A, RX: 1.2 A
