Icom IC-7100 Advanced Instructions

9
D-STAR OPERATION <ADVANCED>
9-48
You can move Your call signs to rearrange their display
order.
It is easy to find stations that you often communicate if
the stations are moved to the top of the memory.
Push q
SET
(C) to enter the Set mode.
Touch the “Your Call Sign” item of the “DV Memory” w
Set mode.
DV Memory > Your Call Sign
• If the specied item is not displayed, touch [∫] or [√](D)
one or more times to select the page
.
• The your call sign list are displayed.
Touch the call sign you want to move for 1 second. e
• If the specied call sign is not displayed, touch [∫] or [√]
(D) one or more times to select the page
.
Touch “Move.” r
• “DESTINATION” blinks on the upper left of the LCD.
t Touch the location to insert the call sign you want
to move, which will be above the memory name se-
lected in this screen.
• The selected call sign is inserted to above the destina-
tion.
• When “<<Move End>>” is selected, the selected call sign
is moved to the bottom of the YOUR CALL SIGN screen.
Select a Your
call sign you
want to move.
Rearrange the display order of Your (destination) call sign
“TOM/7100” is
moved to the
bottom.
Touch “Move”
Touch
[∫]/[√].
Touch the
call sign for
1 second.
Select the
destination
Blinks
Blinks
The L, R, C or D in the
instructions indicate the
part of the controller.
L: Left side
R: Right side
C: Center bottom
D: Display (Touch screen)
L
eft
R
ight
C
enter
D
isplay
Previous view

Icom IC-7100 Specifications

General

Supply	13.8 V DC ±15%
Voltage	13.8 V DC
Operating Temperature	-10°C to +60°C
Frequency Coverage	0.030-199.999 MHz, 400-470 MHz
Modes	SSB, CW, AM, FM, DV
Output Power	HF/50MHz: 100W, 144MHz: 50W, 430MHz: 35W
Receiver Type	Superheterodyne
Antenna Connector	SO-239 (HF/50MHz/144MHz), N-type (430MHz)
Weight	Main unit: 2.3 kg
Type	Base/Mobile
Frequency Range TX	1.8–54 MHz, 144–148 MHz, 430–450 MHz
Frequency Range RX	0.030–199.999 MHz, 400–470 MHz
Memories	505
Current Consumption	TX: 22 A, RX: 1.2 A
