Icom IC-7100 Advanced Instructions

14
VOICE MEMORY FUNCTION
14-10
The transceiver can record the transmit and receive au-
dio into the same file.
Push q
SET
(C) to enter the Set mode.
Touch the “File Split” item of the “Voice Memo” Set w
mode.
( Voice Memo > QSO Recorder > Recorder Set >
File Split)
• If the specied item is not displayed, touch [∫] or [√](D)
one or more times to select the page.
Touch “OFF.” e
• OFF : The transceiver records the transmit and receive
audio into the same file.
• ON : The transceiver records the transmit and receive
audio into each file.
The transceiver makes separate new files for
transmit and receive audio. (Default setting)
• When you set the RX REC Condition item to
“Squelch Auto,” the transceiver records audio to
the new file when the squelch either opens or
closes.
( Voice Memo > QSO Recorder > Recorder set >
RX REC Condition)
Push r
SET
(C) to exit the Set mode.
NOTE: Even if you set the “File Split” item to OFF,
when the recording file’s content becomes 2 GB, the
transceiver continues to record, but to a new file.
About the VOICE PLAYER screen when recording
into the same le
The VOICE PLAYER screen shows information that
is recorded first.
When the receive audio was recorded first, the trans-
mit audio information is not displayed on the screen.
Record the transmit and receive audio into the same le
SET
Touch
“File Split.”
Touch
“Voice Memo.”
Touch
“QSO Recorder.”
Touch
“OFF.”
Touch
“Recorder Set.”
Previous view

Icom IC-7100 Specifications

General

Supply	13.8 V DC ±15%
Voltage	13.8 V DC
Operating Temperature	-10°C to +60°C
Frequency Coverage	0.030-199.999 MHz, 400-470 MHz
Modes	SSB, CW, AM, FM, DV
Output Power	HF/50MHz: 100W, 144MHz: 50W, 430MHz: 35W
Receiver Type	Superheterodyne
Antenna Connector	SO-239 (HF/50MHz/144MHz), N-type (430MHz)
Weight	Main unit: 2.3 kg
Type	Base/Mobile
Frequency Range TX	1.8–54 MHz, 144–148 MHz, 430–450 MHz
Frequency Range RX	0.030–199.999 MHz, 400–470 MHz
Memories	505
Current Consumption	TX: 22 A, RX: 1.2 A
