8
D-STAR OPERATION <BASIC>
8-13
D Using the TX History
Repeaters you transmitted to in the DR mode are stored
in the TX History, and you can select a repeater from
the TX History as your access repeater.
The TX History stores up to 10 of the latest “FROM”
(Access repeater) repeaters.
Push q
DR
(C) to select the DR mode.
Check whether or not “FROM” is selected. w
• If “FROM” is not selected, touch the “FROM” eld.
Touch the “FROM” field. e
The “FROM SELECT” screen appears.
Touch “TX History. r
The “TX HISTORY” screen appears.
Touch the repeater to use as your access repeater. t
• Example: “Hirano”
The transceiver returns to the DR mode screen, and the
selected repeater is set in “FROM.
When you push
QUICK
(C) in the step r, you can
display detailed repeater information on the TX HIS-
TORY screen, or delete it from there.
“FROM” is
selected.
Touch
“FROM”
Touch
“TX History”
“Hirano” repeater is selected in
“FROM.
Touch the
repeater
( Example:
Hirano)
“FROM” (Access repeater) setting (Continued)
L
eft
R
ight
C
enter
D
isplay
The L, R, C or D in the
instructions indicate the
part of the controller.
L: Left side
R: Right side
C: Center bottom
D: Display (Touch screen)
