Icom IC-7100 Advanced Instructions

11
MEMORY OPERATION
11-4
Two Call channels (C1/C2) are selectable in each of the
144 and 430 MHz frequency bands.
Factory default frequencies and operating modes are
programmed into the Call channels. Change these to
suit your operating needs.
Select q the 144 or 430 MHz frequency band. (p. 3-6)
Push w
TUNER/CALL
(L) to select the Call channel of the
selected frequency band.
• “CALL1” appears.
• Rotate [M-CH] to select “CALL2.”
Push e
TUNER/CALL
(L) again to return to the previous
screen display.
While in the Call channel mode
Appears
TUNER/CALL
Selecting a Call channel
Previous view

Icom IC-7100 Specifications

General

Supply	13.8 V DC ±15%
Voltage	13.8 V DC
Operating Temperature	-10°C to +60°C
Frequency Coverage	0.030-199.999 MHz, 400-470 MHz
Modes	SSB, CW, AM, FM, DV
Output Power	HF/50MHz: 100W, 144MHz: 50W, 430MHz: 35W
Receiver Type	Superheterodyne
Antenna Connector	SO-239 (HF/50MHz/144MHz), N-type (430MHz)
Weight	Main unit: 2.3 kg
Type	Base/Mobile
Frequency Range TX	1.8–54 MHz, 144–148 MHz, 430–450 MHz
Frequency Range RX	0.030–199.999 MHz, 400–470 MHz
Memories	505
Current Consumption	TX: 22 A, RX: 1.2 A
