3
BASIC OPERATION
3-9
D Selecting ‘kHz’ step
When the ‘kHz’ Quick Tuning is selected, the frequen-
cy can be changed in the selected ‘kHz’ steps. The
steps can be memorized, depending on the operating
modes.
On the Mode selection screen, select the desired op- q
erating mode. (p. 3-17)
Touch the kHz digits for 1 second to enter the Tuning w
step selection screen.
• The ‘kHz’ Quick Tuning function is turned ON, and then
the “Z” icon is displayed.
Touch the desired tuning step to e
select the desired
‘
kHz
’
step.
• 0.1, 1, 5, 6.25, 9, 10, 12.5, 20, 25, 50 and 100 kHz are
selectable.
• If the desired step is not displayed, touch [Y] or [Z](D)
to select the page.
• On the Tuning step selection screen, rotating the Dial
also selects the tuning step.
• If desired, touch [](D) or push
(C) to return to
the normal operating screen.
Repeat steps r q to e to select the Quick tuning
steps for other modes.
Setting frequency (Continued)
The L, R, C or D in the
instructions indicate the
part of the controller.
L: Left side
R: Right side
C: Center bottom
D:
Display (Touch screen)
D Selecting 1 Hz step
You can change the frequency in 1 Hz steps for fine
tuning.
Touch the Hz digits for 1 second to turn the 1 Hz tun- ➥
ing step ON or OFF.
NOTE:
• When the RIT function is used, it also tunes in 1 Hz
tuning steps.
• The frequency changes in 50 Hz steps when the
[UP]/[DN] switches of the microphone are used for
frequency tuning (if the quick tuning function is not
selected.)
Touch the kHz dig-
its for 1 second
• Tuning step selection screen
Selects pages
Cancel edit
Touch the Hz dig-
its for 1 second
1 Hz indication
