PANEL DESCRIPTION
1-11
Push ➥
to change the set of functions assigned
to touch keys.
• Toggles the function display menu between M-1, M-2 and
M-3 menus or D-1 and D-2 menus.
• Functions vary, depending on the operating mode.
• In the DR mode, the D-1 and D-2 menus can be select-
ed.
Touch or touch for 1 second to select the displayed ➥
functions.
D M-1 (M-1 menu) Display
D M-2 (M-2 menu) Display
(Mode: SSB)
(Mode: SSB-D)
(Mode: CW)
(Mode: RTTY)
(Mode: AM/AM-D)
(Mode: FM/FM-D/WFM)
(Mode: DV)
D M-3 (M-3 menu) Display
(Mode: SSB/AM/AM-D)
(Mode: SSB-D/RTTY)
(Mode: CW)
(Mode: FM/FM-D/WFM/DV)
D D-1 (D-1 menu) Display
(Mode: DV, when the DR mode is selected)
D D-2 (D-2 menu) Display
(Mode: DV, when the DR mode is selected)
Controller — Multi-function keys
