Icom IC-7100

10
GPS/GPS-A OPERATION
10-22
In the DV mode, this function automatically transmits
the GPS receiver’s current position data, at a selected
interval, and should only be used in Simplex transmis-
sion.
NOTE:
• Your own call sign must be entered to activate the
GPS automatic transmission.
• When the “GPS Select” item on page 10-2 is set to
“OFF” or “Manual,” this function is disabled.
GPS > GPS Set > GPS Select
D Setting the GPS automatic transmission
Push q
SET
(C) to enter the Set mode.
Touch the “GPS Auto TX” item of the “GPS” Set w
mode.
GPS > GPS Auto TX
• If the specied item is not displayed, touch [∫] or [√](D)
one or more times to select the page.
Touch to select the desired position transmit interval e
between OFF, 5*, 10, 30 seconds, or 1, 3, 5, 10, and
30 minutes.
• If four GPS sentences are selected in GPS Sentence
menu on page 10-16, “5sec” cannot be selected.
• Selecting “OFF” cancels the GPS automatic transmis-
sion.
• The GPS message is also transmitted, if programmed.
Push r
SET
(C) to exit the Set mode.
NOTE:
• Use GPS automatic transmission in only the sim-
plex mode.
• GPS automatic transmission through a repeater
may interfere with other communications.
When a GPS message is programmed, the trans-
ceiver transmits it along with the position data. See
page 10-17 for the GPS message programming.
The L, R, C or D in the
instructions indicate the
part of the controller.
L: Left side
R: Right side
C: Center bottom
D: Display (Touch screen)
L
eft
R
ight
C
enter
D
isplay
Touch “GPS.”
Touch
“GPS Auto TX.”
Touch the
desired transmit
interval.
GPS Auto transmission for only Simplex
