13
USING AN SD CARD
13-12
For easy operation, the repeater list is preloaded into
your transceiver.
This section describes how to manually update the re-
peater list using an SD card.
The latest setting file, which includes the repeater list,
can be downloaded from the Icom website.
Downloading the latest setting le (ICF le)1.
q Access the following URL to download the latest
data.
http://www.icom.co.jp/world/support/download/rm/
index.html
• The latest settings le (ICF le) and repeater list (CSV;
Comma Separated Values file) are contained in the
downloaded ZIP file.
File Name: 7100_U_130301.zip
Depending on the
updated file date.
Depending on the version.
This instruction manual describes when the file name
is “7100_U_130301.zip,” for example.
w Decompress the compressed file that is downloaded
from the Icom website.
“7100_U_130301” folder will be created in the same
place where the downloaded file is saved.
Inserting the SD card into a PC2.
e Insert the SD card into the SD card drive on your
PC.
• Icom recommends that you format all SD cards to
be used with the IC-7100, even preformatted SD
cards for PCs or other uses.
See page 13-4 and 13-5 for details of inserting and
removing the SD card.
Copying the latest ICF le to the SD card3.
r Double-click the “7100_U_130301” folder created in
the same place where the downloaded file is saved.
t Copy the ICF le (Example: “7100_USA_130301.
icf”) in the folder to the “Setting” folder in the “IC-
7100” folder of the SD card.
Continued on the next page ☞
Click
Click
IC-7100
Cloning software(Rev. MM) and manuals
2013/6/MM
IC-7100’s latest setting file is uploaded to
“Cloning software(Rev. MM) and manuals” in
the Icom website screen.
• The displayed contents may differ.
Updating the repeater list
SD card
Transceiver
to the Card
reader
PC
To Next Page
