Icom IC-7100 Advanced Instructions

9
D-STAR OPERATION <ADVANCED>
9-30
Repeater name programming2.
y Touch “NAME” to enter the repeater name edit
mode.
• A cursor appears and blinks.
Touch the desired block one or more times to u select
the desired character or symbol.
Selectable characters and symbols
A to Z, a to z, 0 to 9, ! # $ % & \ ? " ’ ` ^
+ – ✱⁄ . , : ; = < > ( ) [ ] { } ¦ _ ¯ @ (space)
• Touch “AB⇔12” to toggle between the Alphabet input
and Number input mode.
• Touch [CLR](D) to delete the selected character, symbol
or number.
• Touch [ [AB] ](D) to open the input mode selection win-
dow.
• Touch “  ” to input a space.
Touch [ i f](D) to move the cursor backwards, or
touch [g](D) to move the cursor forwards.
o Repeat steps u and i to enter a name of up to 16
characters, including spaces.
!0 After entering the name, touch [ENT](D).
Input mode selection window
Example:
“East Tokyo”
☞ Continued on the next page.
Repeater list programming (Continued)
Name edit screen
Input a space
Move the cursor
Move the cursor
Delete a character
Select an input mode
Enter
Cancel edit
Open an input
mode window
The L, R, C or D in the
instructions indicate the
part of the controller.
L: Left side
R: Right side
C: Center bottom
D: Display (Touch screen)
L
eft
R
ight
C
enter
D
isplay
Touch
“NAME”
Touch [ENT]
Previous view

Icom IC-7100 Specifications

General

Supply	13.8 V DC ±15%
Voltage	13.8 V DC
Operating Temperature	-10°C to +60°C
Frequency Coverage	0.030-199.999 MHz, 400-470 MHz
Modes	SSB, CW, AM, FM, DV
Output Power	HF/50MHz: 100W, 144MHz: 50W, 430MHz: 35W
Receiver Type	Superheterodyne
Antenna Connector	SO-239 (HF/50MHz/144MHz), N-type (430MHz)
Weight	Main unit: 2.3 kg
Type	Base/Mobile
Frequency Range TX	1.8–54 MHz, 144–148 MHz, 430–450 MHz
Frequency Range RX	0.030–199.999 MHz, 400–470 MHz
Memories	505
Current Consumption	TX: 22 A, RX: 1.2 A
